Glorient offers competitive supply of SCHUNK IN 40-O-M8, Order No: 301484. Competitive pricing, fast quotation.
SCHUNK IN 40-O-M8 - high-precision automation component from SCHUNK, the global leader in gripping systems and clamping technology.
| Weight [kg] | 0.013 kg |
| Min. ambient temperature [°C] | -25.0 °C |
| Max. ambient temperature [°C] | 70.0 °C |
| Measuring principle | inductive |
| Switching function | Opener |
| Type of switching | PNP |
| Number of switching points | 1 |
| Switching distance [mm] | 0.8 |
| Switching hysterisis from the nominal switching distance | < 5% |
| Max. switching frequency [Hz] | 3000.0 |
| LED display in sensor | yes |
| Type of voltage | DC |
| Nominal voltage | 24.0 |
| Min. operating voltage | 10.0 |
| Max. operating voltage | 30.0 |
| Voltage drop [V] | 0.6 |
| Max. switching current | 0.2 |
| Short circuit protection | yes |
| Protected against polarity reversal | yes |
| Housing material | stainless steel |
| Cable connector/cable end | M8 connector, 3-pin |
| Cable length L [cm] | 30.0 |
| Cable diameter D [mm] | 3.3 |
| Cable design (wire cross section/number of wires) | 3x 0.14mm2 |
| Cable sheath material | PUR |
| Min. bending radius (dynamic) [mm] | 34.0 |
| Min. bending radius (static) [mm] | 17.0 |
| Protection class IP (sensor, plugged) | 67 |
| Drilling emulsion resistance * | yes |
