WIKA s 212.40PM, 213.40PM

WIKA is a global market leader in pressure and temperature measurement technology. With over 75 years of experience, WIKA instruments are trusted in process industries worldwide. Glorient is a professional supplier of genuine WIKA products with competitive pricing and fast worldwide delivery.

Excellent load-cycle stability and shock resistance Front flange for panel mounting Solid forged-brass case and connection

Design ASME B40.100 & EN 837-1 Sizes 3½” (80 mm) Accuracy class ± 2/1/2% of span (ASME B40.100 Grade A) Ranges Vacuum / Compound to 200 psi (16 bar) Pressure from 15 psi (1 bar) to 15,000 psi (1,000 bar) or other equivalent units of pressure or vacuum Working pressure Steady: 3/4 scale value Fluctuating: 2/3 full scale value Short time: full scale value Operating temperature Ambient: -40°F to +140°F (-40°C to +60°C) - dry -4°F to +140°F (-20°C to +60°C) - glycerine filled Medium: max. +140°F (+60°C) ≤1,000 psi Temperature error Additional error when temperature changes from reference temperature of 68°F (20°C) ±0.4% of span for every 18°F (10°K) rising or falling. Weather protection Weather resistant (NEMA 4 / IP 66) Pressure connection Material: copper alloy 1/4” NPT lower back mount (LBM) Bourdon tube Material: copper alloy ≤ 1,000 psi (70 bar): C-shape copper alloy > 1,000 psi (70 bar): Helical stainless steel Movement Copper alloy Dial White aluminum with black lettering Pointer Black aluminum Case Gold-painted forged brass with integral connection and pressure relief plug with polished stainless steel front flange. Suitable for liquid filling Window Acrylic with Buna-N gasket
